22 kW AC three-phase 400/480 Vac
7.3 kW AC single-phase 230/240 Vac
Parallel connections until 5 units
SAE J1772 and EN 61851 fully compliance
DC fast charging (CCS) communication (optional)
HVDC connector external interlock monitoring
Typical efficiency >94%
High AC input power factor and low THD
AC/DC galvanic isolation assures a definitive safety separation
between the vehicle and grid
IP67, IP6K9K protection rating
Outputs are short-circuit and reverse polarity protected
Fully CAN controlled by MTA proprietary protocol (v2.0B)
SAE J1939 compliance
De-rated for extreme durability
- -
